The vehicle chassis safety inspection system consists of a vehicle underbody scanner, system host, intelligent controller, power control, vehicle detector, ground induction loop, barrier gate, scene camera, signal light, environmental control equipment, etc.
1. Underbody scanning imaging system
Underbody scannerIt is the core equipment of the vehicle underbody safety inspection system. This system employs advanced linear array scanning cameras and optical lenses to complete the scanning and imaging of the vehicle chassis. Install the vehicle underbody scanning equipment at the outdoor crossing. Its high-strength metal box has a strong pressure resistance capacity and can withstand no more than 30 A heavy load of tons. The entire equipment is installed in a closed manner to ensure its waterproof, moisture-proof and dust-proof functions. Meanwhile, the box is equipped with professional environmental control devices to automatically adjust the ambient temperature and humidity, ensuring that the system meets the requirements for normal operation around the clock. Equipment adoption DC12V Low-voltage power supply ensures the safety of personnel using the equipment during operation.
2. System host
The system host is processed and controlled by the system data nuclear heart set Prepare, it by one Taiwan High sex can the work control PC bear ren hard The platform, and Windows Or use a domestic system as the operating platform. The core software of the system is fully modular and mainly operated by the main program and parameters Setting programs, system maintenance programs, and intelligence IO It is composed of software modules such as the controller online programming program, license plate recognition program, offline viewing program for vehicle underbody images, and scene video playback program. The system host can be selected to support the collection and control of individual unitsColor imaging equipment for vehicle chassisIt is also possible to choose to support the acquisition and control of multiple sets of vehicle chassis color imaging equipment.
3. "Intelligent" IO Controller
"Adopt IO Maximize the provision of intelligent input acquisition and output control devices Input detection and road output control, through RS232 or RS422 The interface is connected to the system host. To ensure the stability of the equipment and its high adaptability in harsh environments, high-performance microprocessors are adopted internally to complete data acquisition, control and communication with external devices. The controller can provide a variety of external interfacesTTLSwitchDC12V All kinds of auxiliary detection devices such as traffic lights, barrier gates and anti-collision walls can be interlocked and controlled.
